Acoustic Doppler Current Profiler

FlowQuest 600 is ideal for measuring flows and flows in the sea, ports, lakes and rivers, and for measuring waves in seas and coastal areas. With a longer measuring range, standard water depth tolerance and the ability to integrate with other sensors and LinkQuest sound modems, 600 kHz operating frequency.

Feature: Measuring section and depth

Velocity:

• Frequency: 600 kHz
• Accuracy: 0.25% or 2.5 mm / s
• Cell size: 0.5 to 4m
• Maximum water velocity: 20 knots (10.28 m / s)
• Number of cells: 170
• Maximum pulse speed: 2 / sec

Standard sensors:

• Conpass: Accuracy: ±2^o
• Tilt: 0,5o to ±15^o
• Temparature: Accuracy: 0,4^oC; Range: -5oC to 45^oC ;

Pressure: Accuracy: 0.25%.
